Key Features



Reliability, Durability, and Efficiency

The specificity of Opti series filters lies in their ability to combine reliability, efficiency, ease of maintenance, and versatility, thus providing a complete solution for maintaining clean and healthy water in a variety of aquatic environments. They are a preferred option for those who demand quality water and exceptional longevity.

Reliability and durability: These filters stand out for their robust construction and ability to withstand high pressures, ensuring exceptional longevity even in demanding environments.

Ease of Maintenance

Ease of maintenance is one of the strengths of these filters. Their intelligent design allows for quick cleaning and replacement of filter elements, minimizing downtime. This feature ensures efficient and fast maintenance, guaranteeing continuous and optimal operation of your filtration system.

Versatility

These filters offer extensive compatibility with various filtration pumps, making it easy to integrate them into a variety of existing filtration systems. This versatility ensures a solution tailored to a wide range of applications, providing flexibility appreciated by users.

  TOP 450 TOP 500 TOP 650
Reference PF-OPT450T PF-OPT500T PF-OPT650T
Maximum Flow Rate (m³/h) 7.80 10.80 15.30
Filtration Surface (m²) 0.16 0.22 0.31
Addressable Volume
(m³ in approximate 6h time)		 45 60 90
Inlet / Outlet Connections 1.5" / 50mm
Diameter (mm) 450 500 650
Sand (kg) / Glass (kg) 45 / 35 85 / 70 145 / 180
Dimensions (AxBxC) 814 x 698 x 638 845 x 730 x 670 950 x 835 x 775
Garantie Cuve : 5 ans / Vanne : 2 ans



```html
  SIDE 450 SIDE 500 SIDE 650 SIDE 700
Référence PF-OPT450S PF-OPT500S PF-OPT650S PF-OPT700S
Maximum Flow Rate (m³/h) 7.80 10.80 15.30 19.20
Filtration Area (m²) 0.16 0.22 0.31 0.39
Addressable Volume
(m³ in approximate 6h time)		 45 60 90 110
Inlet / Outlet Connections 1.5" / 50mm
Diameter (mm) 450 500 650 700
Sand (kg) / Glass (kg) 45 / 35 85 / 70 145 / 180 210 / 170
Dimensions (AxBxC) 360 x 420 x 730 390 x 450 x 770 430 x 490 x 850 450 x 510 x 960
Warranty Tank: 5 years / Valve: 2 years

Valve
Tank
